Zigbee PIR motion sensor

Your protector and assistant at detecting the movements a persons. It will monitor changes in your space. The full potential of the sensor opens when connected to other smart devices. The device is able to activate even the most complex scenarios that are limited only by human imagination

Want to buy or have questions?

Mycond

Smart sensors and accessories

MyCond Smart Zigbee PIR motion sensor for automated home systems.

Features

The PIR motion sensor detects human motion and notifies the gateway, while sending a push alarm notification to the user's mobile phone. The sensor is suitable for use in a private house, a hotel, or an office.

Detection angle 90°
Rotation angle 360°
Detection distance up to 8 m
Low battery reminder
Status report
Low power consumption

Play

Parameters	Motion sensor
Power	DC 3V (CR123A)
Battery life	up to 1 year (20 times per day)
Working conditions	from -10°C to +55°C, 10-90% RH (no condensation)
Installation height	up to 2,2m
Rotation angle	360°
Detection angle	90°
Wireless communication	Zigbee 3.0
Material	ABS+PC
Net weight	47,5g
Dimension	Ø48,4mm*53,4mm
